Технические характеристики HS151 Crouzet Радиатор : • 1.5°C/W Thermal resistance • Suitable for 1 single or dual SSR • DIN rail or panel mounting GENERAL SPECIFICATIONS Description Panel Mount Din-Rail Mount Model Number HS151 HS151DR Thermal resistance [°C/W] 1.5 1.5 Surface area [in²/cm²] 138/891 138/891 Heat sink mounting Panel Mount Panel or Din-Rail Mount Weight [lbs/grs] 0.85/319 0.92/350 Material Aluminum Aluminum Finish Black Anodized Black Anodized SSR Mounting Holes/ threads 2, 8x32 2, 8x32 Mounting screw torque [in lbs/nm] 15-20/1.7-2.2 15-20/1.7-2.2 Number and type of relay accepted 1 single or dual 1 single or dual Accepts Fan/size [mm] Yes/ 2-40 Yes/ 2-40
