Техническое описание на ZP-2LH Частотный смеситель : Level 10 (LO Power +10 dBm) Parameter Min. Typ. Max. Units Frequency LO (fL to fU) 50 1000 MHz RF (fL to fU) 50 1000 MHz IF 0 1000 MHz Conversion Loss mid band 5.2 7.0 dB Total Range 8.5 dB LO-RF Isolation Low Range 40 58 dB Mid Range 30 44 dB Upper Range 25 39 dB LO-IF Isolation Low Range 35 60 dB Mid Range 25 50 dB Upper Range 20 38 dB Notes: Low Range = 50 to 100 MHz] Mid Range = 100 to 500 MHz Upper Range = [fU/2 to fU] mid band = [2fL to fU/2]
