Техническое описание на ZABDC10-25HP-S Сплиттер : 50Ω Up to 10W 1500 to 2500 MHz Maximum Ratings Coaxial Connections INPUT 1 OUTPUT 4 COUPLED (forward) 2 COUPLED (reverse) 3 Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C DC Current 3.0A Features • excellent directivity, 26 dB typ. • low mainline loss, 0.55 dB typ. • high power, up to 10W • rugged shielded case • DC Current through input to ouput 3.0A Max. at 1.0 Watt RF input power. Applications • PCS/DCS/UMTS • power leveling & monitoring • VSWR measurement
