Техническое описание на ZMSC-3-2 Сплиттер : 3 Way-0° Parameter Min. Typ. Max. Units Frequency 0.001 30 MHz Isolation* 0.01-0.01MHz 30 35 dB 0.1-15MHz 25 40 dB 15-30MHz* 25 30 dB Insertion Loss Above 4.8 dB 0.01-0.1MHz 0.25 0.45 dB 0.1-15MHz 0.15 0.45 dB 15-30MHz 0.45 0.75 dB Phase Unbalance 0.01-0.1MHz 1 deg. 0.1-15MHz 2 deg. 15-30MHz 4 deg. Amplitude Unbalance 0.01-0.1MHz 0.2 dB 0.1-15MHz 0.3 dB 15-30MHz 0.4 dB MAXIMUM RATINGS Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input 1W max. Internal Dissipation 0.375W max.
