Техническое описание на ZN3PD-900W-S Сплиттер : 3 Way-0° 50Ω 650 to 1050 MHz Maximum Ratings Coaxial Connections SUM PORT S PORT 1 1 PORT 2 2 PORT 3 3 Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 10W max. Internal Dissipation 0.375W max Features • low insertion loss, 0.3 dB typ. • good isolation, 22 dB typ. • excellent VSWR • up to 10W power input as splitter • rugged shielded case Applications • instrumentation • cellular • communications systems
