Техническое описание на ZN4PD-ED14480/1 Сплиттер : 4 Way-0° Parameter Min. Typ. Max. Units Frequency 500 2700 MHz Isolation 19 dB Insertion Loss Above 6.0 dB 1.60 dB Phase Unbalance 6.00 deg. Amplitude Unbalance 0.80 dB VSWR SUM Port 1.50 (:1) OUT Ports 1.30 (:1)
