Техническое описание на ZN4PD1-50-S+ Сплиттер : 4 Way-0° 50Ω 500 to 5000 MHz Maximum Ratings Coaxial Connections SUM PORT 3 PORT 1 1 PORT 2 2 PORT 3 4 PORT 4 5 Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 10W max. Internal Dissipation 0.75W max. Features • wideband, 500 to 5000 MHz • high isolation, 23 dB typ. • good input matching VSWR, 1.3:1 typ. • up to 10W power input as splitter Applications • UHF TV • ISM • cellular/ISM/GSM • MMDS • satellite distribution • SATCOM • GPS/L-BAND (MARSAT) • PCS/DCS/UMTS
