Техническое описание на ZN4PD1-63W-S+ Сплиттер : 4 Way-0° 50Ω 250 to 6000 MHz Maximum Ratings Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 10W max. Internal Dissipation 3W max. Coaxial Connections SUM PORT 3 PORT 1 1 PORT 2 2 PORT 3 4 PORT 4 5 Features • wide frequency band, 250 to 6000 MHz • low insertion loss, 1.0 dB typ. • low amplitude unbalance 0.2 dB typ. • low phase unbalance 2 deg. typ. Applications • high band PCS • UNII • ISM 802.11A • WiFi • Bluetooth
