Описание
Техническое описание на ZN8PD-642W-S+ Сплиттер : 8 Way-0° 50Ω 1800 to 6400 MHz Maximum Ratings Coaxial Connections SUM PORT S(COM) PORT 1,2,3,.....,8 1,2,3.....,8 Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 10W max. Internal Dissipation 0.875W max. Features • wideband, 1800 to 6400 MHz • low insertion loss, 1.5 dB typ. • low amplitude unbalance, 0.2 dB typ. • excellent output VSWR, 1.15:1 typ. • DC PASS from sum port to output ports Applications • high band PCS • UNII • WIMAX • WiFi • bluetooth
