Описание
Техническое описание на ZSC-2-1W+ Сплиттер : 2 Way-0° 50Ω 1 to 650 MHz Maximum Ratings Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 1W max. Internal Dissipation 0.125W max Features • wideband, 1 to 650 MHz • low insertion loss, 0.5 dB typ. • high isolation, 35 dB typ. • excellent amplitude unbalance, 0.1 dB typ. • excellent phase unbalance, 0.5 deg. typ. • rugged shielded case Applications • VHF/UHF • federal & defense communications • instrumentation
