Описание
Техническое описание на ZSC-2-4BR+ Сплиттер : 2 Way-0° 50Ω 10 to 1000 MHz Maximum Ratings Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 1W max. Internal Dissipation 0.125W max. Features • wideband, 10 to 1000 MHz • low insertion loss, 0.5 dB typ. • high isolation, 35 dB typ. • excellent amplitude unbalance, 0.1 dB typ. • excellent phase unbalance, 1 deg. typ. • excellent VSWR, 1.15:1 typ. • rugged shielded case Applications • VHF/UHF • cellular • communication systems
